| BASIC INFORMATION | ||
| Rated Capacity | ||
| Cooling | Btu | 18000 |
| Heating | Btu | 18500 |
| Rated Running Current | ||
| Cooling | A | 1.1-8.6 |
| Heating | A | 1.2-7.8 |
| Max. Input Power | W | 2650 |
| Max. Input Current | A | 11 |
| SEER Cooling | W/W | 8.5 |
| SCOP Heating | W/W | 4.6 |
| Power Supply Source | V/Ph/Hz | 220～240V-1-50Hz |
| Refrigerant | R410A | |
| Refrigerant Charged | g | 1600 |
| Max. Discharge Pressure | Mpa | 4.15 |
| Max. Suction Pressure | Mpa | 1.15 |
| Air Flow Volume | m3/h | 1150 |
| Indoor Unit Noise Power | dB(A) | 44 |
| Outdoor Unit Noise Power | dB(A) | 54 |
| Indoor Unit Weight(Net) | Kg | 15 |
| Outdoor Unit Weight(Net) | Kg | 47 |
| Container Loading 40HC | Units | 138 |
| INDOOR UNIT | ||
| Evaporator | ||
| Bend | 3 | |
| Evaporator Row | 2 | |
| Evaporator Pipe Diameter | mm | 7×0.24 |
| Indoor Fan Motor | D-310-50-8 | |
| Dimension | ||
| Net Dimension | mm | 1132x330x232 |
| Packing Dimension | mm | 1205x400x317 |
| CONNECTION | ||
| Stop Valve | ||
| Gas Valve | mm | Φ6.35 |
| Evaporator Row | mm | Φ12.70 |
| OUTDOOR UNIT | ||
| Compressor Brand | Highly | |
| Compressor Model | ATD141 | |
| Outdoor Fan Motor | D-69-8 | |
| Condenser Pipe Diameter | mm | 7×0.24 |
| Condenser Row | 2 | |
| Dimension | ||
| Net Dimension | mm | 900x343x681 |
| Packing Dimension | mm | 1020x430x770 |
