| BASIC INFORMATION | ||
| Rated Capacity | ||
| Cooling | Btu | 24000 |
| Heating | Btu | – |
| Rated Running Current | ||
| Cooling | A | 13.5 |
| Heating | A | – |
| Max. Input Power | W | 2656 |
| Max. Input Current | A | 15 |
| EER Cooling | W/W | 3.11 |
| COP Heating | W/W | – |
| Power Supply Source | V/Ph/Hz | 220～240V-1-50Hz |
| Refrigerant | R410A | |
| Refrigerant Charged | g | 1400 |
| Max. Discharge Pressure | Mpa | 4.3 |
| Max. Suction Pressure | Mpa | 1.15 |
| Air Flow Volume | m3/h | 1250 |
| Indoor Unit Noise Power | dB(A) | ≤51 |
| Outdoor Unit Noise Power | dB(A) | ≤61 |
| Indoor Unit Weight(Net) | Kg | 14 |
| Outdoor Unit Weight(Net) | 60 | |
| Container Loading 40HC | Units | 150 |
| INDOOR UNIT | ||
| Evaporator | ||
| Bend | 7 | |
| Evaporator Row | 2 | |
| Evaporator Pipe Diameter | mm | Φ7×0.24 |
| Indoor Fan Motor | D-310-50-8A | |
| Dimension | ||
| Net Dimension | mm | 1100×330×235 |
| Packing Dimension | mm | 1180×400×317 |
| CONNECTION | ||
| Stop Valve | ||
| Liquid Valve | mm | Dg4 |
| Gas Valve | mm | Dg13 |
| OUTDOOR UNIT | ||
| Compressor Brand | KK | |
| Compressor Model | AW5524B | |
| Outdoor Fan Motor | YDK69-6B | |
| Condenser Pipe Diameter | mm | 7.94 |
| Condenser Row | 2 | |
| Dimension | ||
| Net Dimension | mm | 825×655×310 |
| Packing Dimension | mm | 945×725×435 |
