| BASIC INFORMATION | ||
| Cooling | ||
| Capacity | Btu/h | 19445 |
| Input | W | 2716 |
| Rated Current | A | 12.56 |
| EER | W/W | 7.16 |
| Max. Input Consumption | W | 3200 |
| Max. Current | A | 16 |
| Starting Current | A | 66.3 |
| Compressor | ||
| Model | AW5528EK | |
| Type | RECIPROCATING | |
| Brand | KK | |
| Capacity | Btu/h | 24100 |
| Input | W | 2270 |
| Rated current(RLA) | A | 11.74 |
| Locked rotor Amp(LRA) | A | 66.3 |
| Thermal protector | KGE 656-8 | |
| Thermal Protector Position | INTERNAL | |
| Capacitor | uF | 50 |
| Refrigerant Oil / Oil charge | ml | MINERAL OIL / 964 |
| Specifications | ||
| Refrigerant Type | g | R22/1300g |
| Design Pressure | MPa | 3.0/1.0 |
| Refrigerant Piping | ||
| Liquid Side/ Gas Side | mm(inch) | Φ9.52/Φ15.9(3/8″/5/8″) |
| Max. Refrigerant Pipe Length | m | 20 |
| Max. Difference In Level | m | 10 |
| Connection Wiring | 4×2.5 | |
| Plug Type | 2.5×3/no-plug | |
| Thermostat Type | Remote Control | |
| Operation Temperature | ℃ | 17~30 |
| Room Temperature | ||
| Indoor(Cooling/ Heating) | ℃ | 17~32/– |
| Outdoor(Cooling/ Heating) | ℃ | 18~52/– |
| Application Area (Cooling Standard) | m2 | 30-44 |
| Container Loading 20′ feet | Unit | 66 |
| Container Loading 40′ feet | Unit | 138 |
| Container Loading 40′ feet High | Unit | 152 |
| INDOOR UNIT | ||
| Indoor Fan Motor | ||
| Model | YKFG-45-4-22 | |
| Input | W | 77 |
| Output | W | 45 |
| Capacitor | uF | 3.0 |
| Speed(Hi/Mi/Lo) | r/min | 1200/1180/1020/950 |
| Indoor Coil | ||
| Number Of Rows | 2 | |
| Tube pitch(a)x row pitch(b) | mm | 21×13.37 |
| Fin spacing | mm | 1.3 |
| Fin type (code) | Hydrophilic Aluminium | |
| Tube outside dia.and Type | mm | Φ7,innergroove Tube |
| Coil length x height x width | mm | 820x336x26.74 |
| Number Of Circuits | 4 | |
| Indoor air flow (Turbo/Hi/Mi/Lo) | m3/h | 1150/1130/960/880 |
| Indoor Noise Level (Turbo/Hi/Mi/Lo) | dB(A) | 48.5/48/43/42 |
| Indoor Unit | ||
| Dimension(WxDxH) | mm | 1080x226x335 |
| Packing (WxDxH) | mm | 1155x415x315 |
| Net Weight | Kg | 14 |
| Gross Weight | Kg | 17.5 |
| OUTDOOR UNIT | ||
| Outdoor Fan Motor | ||
| Model | YKT-75-6-200L | |
| Input | W | 144 |
| Output | W | 75 |
| Capacitor | uF | 3.0 |
| Speed | r/min | 860 |
| Outdoor Coil | ||
| Number Of Rows | 2 | |
| Tube pitch(a)x row pitch(b) | mm | 21×13.37 |
| Fin Spacing | mm | 1.4 |
| Fin type (code) | UnHydrophilic Aluminium | |
| Tube outside dia.and type | mm | Ф7,innergroove tube |
| Coil length x height x width | mm | 755x651x26.74 |
| Number Of Circuits | 4 | |
| Outdoor Noise Level | dB(A) | 60 |
| Outdoor Unit | ||
| Dimension(WxDxH) | mm | 845x363x702 |
| Packing (WxDxH) | mm | 965x395x765 |
| Net Weight | Kg | 55.1 |
| Gross Weight | Kg | 58.2 |
