| Basic Information |
|
USB Device Media Format |
| Product Type |
LED UD Smart ANDROID DTV |
Music |
MP3/AC3/HE-AAC/LPCM/WMA |
| Chassis |
MS88S2 DVB-T2/S2,CI+ |
Picture |
JPEG/BMP/PNG/GIF |
| CPU |
Dual Core A53 1.5GHz |
Mutilmedia Video |
H.264/H.265/MPEG2/MPEG4
/Motion JPEG/VC1 |
| GPU |
Quad Core MALI450MP2 |
|
|
| OS |
Android 5.1.1 |
|
|
| Memory/Flash |
1.5GB DDR3 / 8GB Flash |
|
|
| UI Style |
HTML5 UI, 2 pages UI |
Signal Format Capability |
| Launcher HomePages Show |
Home, App |
| OSD Language |
English,Spain,French,Russian,Arabic,Hebrew，Uzbekistan，Farsi |
| TV System |
PAL B/G、D/K、I；NTSC-M； |
DVI Video Format |
Up to XGA for HDMI-PC |
| DVB-T/T2/S/S2,CI+ |
HDMI Video Format |
up to 1080P |
| AV System |
PAL、NTSC |
PC Compatibility |
—– |
| Channels |
0000-9999 |
|
|
| Power Supply |
AC 110V-240V 50/60Hz |
Panel Specification |
| Power Consumption（TV On） |
160W |
| Power Consumption（Standby） |
≤0.5W |
Backlight Unit |
LED |
| Certification |
CB, HDMI, Dolby,ERP |
Panel supplier |
CSOT ST5461D07-5 |
| ECO Energy efficiency |
Yes |
Aspect Ratio |
16:9 |
| Internet Link |
wireless WiFi Default |
Panel Active Size (inch) |
55″ |
| |
Display Resolution |
3840*2160 |
| Ethernet Network |
Brightness (cd/m2) |
280(mini),300nits(typical) |
| LED Indicator Status |
White in Standby |
Contrast Ratio |
4000:1 |
| Basic Function |
Response Time (G to G) |
8ms |
| Viewing Angle (H/V) |
178°/178° |
| Initial Setup |
Yes，for user setting in TV first starting |
Life Time(Typ.) |
30,000hrs |
| HDMI Auto Switch |
Auto、Close、Manual |
Color |
16.7 Million(8bit) |
| Channels Edit |
For Channel renamed |
Refresh Rate |
60Hz |
| Input Settings |
For Input source device choice |
WCG |
NTSC 85% |
| Sleep Timer |
Yes |
Terminals |
| T-Link（CEC） |
Yes |
| HDMI ARC |
Yes |
HDMI 2.0 |
3 HDMI (include MHL, CEC, ARC) |
| MHL |
— |
USB 2.0 |
1 |
| Teletext |
Yes |
USB 3.0 |
1 |
| S/W update |
Internet s/w update |
AV in |
1 |
| |
USB s/w update |
RJ45 |
1 |
| Power Label |
A |
Audio out |
1 |
| Shop mode |
E-sticker （OEM版本推广） |
Headphone |
1 |
| PVR |
Yes for FTA |
Tuner |
ATV/DVB-T/T2/S/S2 |
| Timeshift |
Yes for FTA |
CI |
1 |
| |
|
SPDIF |
1 |
| Picture |
Sound |
| Picture Mode |
StandardDynamicNaturalMoviePersonal |
Speakers |
Integrated speakers (Bottom side) |
| Screen Mode |
16:94:314:9CinerameZoom etc. |
Audio Power Output（THD=7%） |
2×10W |
| Noise Reduction |
LowMiddleHighAutoOff |
Auto Volume Control |
On / Off |
| Backlight Adjustable |
Yes (0~100) |
Sound Preset |
StandardMusicMovieClear VoicePersonal |
| Color Temperature |
Normal/Warm/Cool/Customer |
Sound Control |
Five band equalizer adjust in Personal mode |
| Gamma Adjustable |
-4 to 4 |
TV Placement |
Desk top / Wall mount |
| Dynamic Contrast |
Yes |
Audio Delay |
Yes |
| Overscan |
Yes |
Bluetooth sub-woofer |
Option |
| Picture Freeze |
Yes |
|
|
| Game Mode |
Yes |
|
|
| Film Mode |
Yes |
|
|
| Picture Reset |
Yes |
|
|
| Application List |
Essential Accessories（Default） |
| YouTube TCL version |
Pre-install, Global Online Movies |
Operation Manual |
English(Default) |
| Golive 3.0 |
Pre-install, Global Online Movies |
Remote Control and batteries |
RC580(with two batteries) + RC880 |
| Mediacenter |
Media/Music play for USB Device |
Base Stand |
Integrated Packaging |
| TED TV |
Pre-install, Global Online Movies |
AC power cord |
1 pcs |
| Browser |
Webpage Browser |
Remote ID Picture |
| Deezer |
Global Online Music Streaming service |
| App Store 3.0 |
Special App Store available for download |
 |
| ZEASN APP STORE |
Option |
| MEGOGO |
Option |
| FAST CAST |
Yes |
| Main app in app store |
Viewster, Dailymotion,Megogo,Icflix,BoxTV, |
|
| TV version google play, News,Weather |
|
| |
|
| E-Sticker |
OEM version function demo in Shop mode |
| nScreen |
Connect Mobile phone to TV sets and control |
| |
the TV like Remote using Phone; |
| |
Push media file in Phone to TV Display and |
|
|
| |
Enjoy big screen picture quality. |
RC880 |
| T-CAST |
Wireless Mirroring connecting,to deliver audio |
|
|
| and video content from smartphone to TV |
|
|
| Wifi direct |
Yes |
|
|
| |
|
|
|
